Thermal Inkjet Printers
Wolke m610 OEM
Thermal Inkjet Printer for Track & Trace Applications
The Wolke m610 OEM thermal inkjet printer — TIJ — represents the gold standard in ensuring product traceability through Track & Trace applications. With its innovative design and unique construction, the m610 OEM offers versatile integration capabilities, combined with comprehensive data collection and global Track & Trace functionality.
It is specially designed to meet current and future serialisation requirements, particularly in the pharmaceutical and tobacco industries.
The Wolke m610 OEM is a printer intended for integration into various types of machines. Thanks to the compact dimensions of the controller and the web server function, the printer can be operated and monitored directly from the machine’s HMI panel, making it an integral part of the packaging machine.
| Specification | Values |
|---|---|
| Maximum print resolution | 600 × 600 dpi |
| Maximum print speed (1) | 300 m/min |
| Barcodes | Linear and 2D codes, including DataMatrix, QR, GS1, PPN, HIBC |
| Print height with one printhead | 12.7 mm |
| Maximum number of printheads | Up to 6 printheads (printing with any 4 simultaneously) |
| Interface | 3.5″ impact-resistant display, automatic screen rotation in any orientation |
| Communication | 24 V DC I/O connector, Ethernet, TCP/IP, FTP, USB-A |
| Protection rating | IP20 (control unit) |
Precise Data Handling for Serialisation Requirements
Secure and very fast processing of 20 unique records per second, including 2D DataMatrix codes and GS1-128 barcodes.
Powerful data processing hardware, ideal for managing serialised records.
Unicode TrueType® fonts for global projects.
Asynchronous communication reduces network traffic.
Maximum Flexibility When Integration Matters
Control unit up to 60% smaller than competing TIJ control units, with 24 V power supply for easy installation in a cabinet.
18 different installation options in various orientations, including adjustable mounting or DIN rail mounting.
Connection of up to six printheads and simultaneous operation of any four printheads, enabling printing in different positions without mechanical adjustment.
Option to operate and configure the printer via the machine’s main HMI.
Advanced Innovations Increase Productivity
Perpetuo Print Mode™ extends the production process and enables ink replacement without stopping the line.
Dynamic Print Intensity™ enables different resolutions to be set for barcodes and text within a single printhead, optimising ink consumption.
Wide range of Wolke TIJ inks for special applications.
