Print&Apply – EuroJumbo
Euro Jumbo Evo is an automatic Print & Apply system designed to apply the last printed label directly onto pallets.
It is specifically engineered for pallet labelling and enables the application of two ISO A5 labels on two sides (front and side) of the pallet corner.
Euro Jumbo Evo prints all types of codes, images, and variable data received from the packaging line, and then automatically applies the freshly printed label.
At the core of the Euro Jumbo Evo system is an industrial thermal transfer printer with dual-processor electronics, equipped with an air-blow application pad that applies labels to the front and side of stationary pallets.
| System specification | Values |
|---|---|
| Print speed | max 150 mm/s |
| Label dimensions (width × length) | min 50 × 50 mm max 150 × 210 mm |
| Print area | max 150 × 210 mm |
| Roll outer diameter | max 280 mm |
| Roll inner diameter | 40–75 mm |
| Ribbon length | 600 m |
| Machine dimensions (L × W × H) | 880 × 830 × 1450 mm |
| Power supply | 115/230 V, 50–60 Hz |
| Compressed air | 6 bar |
| Resolution | 8 dots/mm |
| Barcodes | All standard barcodes |
| Text rotation | 4 directions |
| Interface | RS 232/422 Ethernet 10/100 USB |
| Application precision | Euro Jumbo ensures 100% precision when applying labels to the desired pallet position, with consistent repeatability. |
| Ease of use | Simple operation allows quick switching between products, saving operator time. |
| Reliability | Ensures perfectly printed and applied labels without peeling during transport and handling, and without air bubbles. |
| Application speed | High application speed eliminates production bottlenecks caused by printing and manual labelling, reducing downtime. |
| Real-time printing | Enables printing of fixed and variable data in real time, ensuring better traceability. |
